Specification:
Contacts: 4
Electrical specification:600V@50Amp
Mating: >500
Inline cable: 6 mm2
Contadt resistance: <0.01Ω
rature rating: -4°C~+60°CTempe
BH lead: 6 mm2
Insulation resistance: >200 MO
Depth rating: 6000 meters
Inline cable color code: 1 black 2 white 3 red 4 green

Materialspecification:
Connector body: Chloroprene rubber
Nuts and washers: stainless steel
Snap ring: stainless steel
BH body: 316L stainless steeltitanium
O-rings: Nitrile
Dimensions in mm
Contacts: Gold plated brass
Locking sleeve: POM
Threads in metrics
1 inch = 25.4 mm

Optionsinclude:
1. Cable length
2. Shell material: Stainless steel,titanium
3.Thread length
