Specification:
Contacts: 6
Inline cable:  0.5mm2
BH lead: 0.5mm2
Electrical specification:300V@3-10Amp
Contact resistance: <0.010
Insulation resistance: >200 MO
Temperature rating:-4°C~+60°C
Matings: >500
Depth rating: 6000 meters
Inline cable color code:1 black 2 white 3 red 4 green 5 orange 6 blue
Connector body: Chloroprene rubber
Nuts and washers: Stainless steel
Dimensions in mm
BH body: 316L stainless steel/titanium
O-rings: Nitrile
Threads in metrics
Contacts: Gold plated brass
Locking sleeve: POM(red、black、blue)
1 inch = 25.4 mm
Optionsinclude:
1. Cable length
2. Shell material: Stainless steel,titanium
3.Thread length
