Fiber optic specification:
Transmission mode: Singlemode fiber optic:
Max. loss: Max2.5dB
Wave length: 850-1300nm
Wave length:1310-1650nm
Fiber channel:4
Nominal loss: 1.0-1.5dB
Nominal loss: 1.0-1.5 dB
Multi-mode optical specification:
Max. loss: Max2.5dB

Electrical specification:
Contacts:4
Nominal voltage: 500V
Pigtail connector: ST,LC,FC,SCoptional
Contact specification:1-2 mm2
Depth rating: 6000 meters
Temperature rating(storage):-20C/+60°C
Current rating:6-15 AMP
Wet matings: >1000
Temperature rating(working):-20°C/+50C

Material specification:
Shell: 316L stainless steel(titanium)
Dust cap: Black POM
Dimensions in mm
Fiber optic ferrule: Ceramic
Pressure cap: 316L stainless steel(titanium)
Threads in inches
O-rings: Nitrile
Locking sleeve: Stainless steel
1 inch = 25.4 mm
